Product characteristics
Electrical design PNP
Output function normally open
Sensing range [mm] 3...12
Housing threaded type
Dimensions [mm] M12 x 1 / L = 61
Application
Media dry bulk material; liquids
Electrical data
Operating voltage [V] 10...36 DC; ("supply class 2" to cULus)
Current consumption [mA] < 12
Protection class III
Reverse polarity protection yes
Outputs
Electrical design PNP
Output function normally open
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 100
Switching frequency DC [Hz] 50
Short-circuit proof yes
Overload protection yes
Detection zone
Sensing range [mm] 3...12
Sensing range adjustable yes
Factory setting sensing range [mm] 8
Real sensing range Sr [mm] 8 ± 10 %
Accuracy / deviations
Correction factor glass: 0.6 / water: 1 / ceramics: 0.5 / PVC: 0.4
Hysteresis [% of Sr] 1...15
Switch point drift [% of Sr] -20...20
Operating conditions
Ambient temperature [°C] -25...70
Protection IP 65
Increased immunity yes
